SPECIFICATIONS

Brand Name: toocki

Compatible device: Tablets,Phones

Connectivity: WireLess

Hign-concerned Chemical: None

Microphone Type: Lavalier Microphone

Model: M1

Origin: Mainland China

Polar Pattern: Omnidirectional

TX transmitter

Chip solution: Zhonglan Kexun

Battery capacity: 40~50mAh

Working voltage: Lithium battery 3.7V

Working current:<15mA

Standby power consumption:<10uA

Charging voltage: DC5V

Charging time: about 1 hour

Working endurance time: 2-3 hours

Transmission Protocol: 5.2

Transmission distance: approximately 10m-20m (forward direction)

Microphone sensitivity: -38dB

Noise reduction: Built in noise reduction algorithm

Reverb: Double click the power button with reverb sound effect

Operation:

1. Press and hold for two seconds to turn on the device (the blue light flashes rapidly), and the automatic pairing will be successful (the blue light stays on)

2. Click the power button to mute (slow flashing blue light)

3. Double click the power button to switch the reverberation mode (the red light will light up once)

Turn the blue light on for a long time, then double-click to exit the reverb mode.

4. Press and hold the button for two seconds to shut down (light off)

5. The charging red light stays on and the fully charged light goes off.

RX receiver: Lightning or TYPE C interface

Chip solution: Zhongke Lanxun

Working voltage: Powered by mobile OTG

Working current:<18mA

Charging voltage: DC5V

Charging current: maximum 2A

Transmission Protocol: Bluetooth 5.2

Transmission distance: approximately 15m-25m (forward direction)

Plug and play: automatic power on

Operation:

Unmatched blue light flashes, successfully paired blue light stays on
